Description
380–415V | IP44 | 3P+N+E | CE Approved
Upgrade your power distribution with the ESR 32A Switched Interlock Socket, featuring integrated RCD protection and designed for safe 3-phase operation. With an IP44 splash-proof rating and mechanical interlock, this unit is built for safety and reliability in both commercial and industrial settings.
✅ Key Features:
Rated Current: 32 Amps – suitable for moderate-load 3-phase systems
Voltage Rating: 380–415V AC – ideal for European/UK 3-phase circuits
Pin Configuration: 4-Pin (3P+N+E)
Frequency: 50/60Hz – globally compatible
RCD Facility: Integrated residual current protection for safety
Interlocked Switch: Power can only be activated when plug is properly inserted
IP44 Rating: Splash-proof and dust-resistant – safe for semi-outdoor use
Standard Compliance: BS EN 60309 and CE certified
🛠️ Applications:
Industrial Machinery
Commercial Distribution Panels
Site Power Control Boards
Temporary Outdoor Installations
Generator Hookups
Agricultural Equipment Power Supply
Specifications
| SKU | RCDSI32544 |
|---|---|
| Product Type | Switched RCD Interlock Socket |
| Model | 32A / 4-Pin / 3P+N+E |
| Rated Current | 32 Amps |
| Rated Voltage | 380 – 415V AC |
| Pin Configuration | 3P+N+E (4 Pin) |
| Frequency | 50/60Hz |
| Ingress Protection | IP44 |
| Switching | Rotary switch with mechanical interlock |
| RCD | Included |
| Material | Durable industrial-grade thermoplastic |
| Mounting | Surface mount |
| Standards | BS EN 60309, CE Approved |
| Brand | ESR |
| Length | 46.7 cm |
| Width | 16.25 cm |
| Depth | 20.3 cm |
