Outdoor In-Ground COB LED Strip Lighting Kit – IP67 24V Recessed Aluminium Floor Profile, Diffuser & Drivers | 10m–50m

Create a clean, contemporary line of light across outdoor landscaping and architectural spaces with our professional 24V outdoor in-ground COB LED strip lighting kit. Designed for recessed linear lighting installations, this complete outdoor LED strip pack brings together high-density IP67 FCOB LED tape, correctly matched 24V LED power supplies, and an extra-deep recessed aluminium floor profile with opal diffuser.

The combination of continuous COB (chip-on-board) LED technology and a diffused aluminium channel delivers a smooth, virtually dot-free linear lighting effect, suitable for creating illuminated lines in garden paths, patios, step edges, landscape features, building perimeters and commercial exterior settings. With CRI 90+, the strip is designed to reproduce surrounding materials and colours naturally.

Choose your preferred white-light colour temperature: 3000K warm white for a welcoming ambience, 4000K neutral white for balanced architectural lighting, or 6500K daylight white for a crisp, brighter-looking effect. Available in complete 10m, 20m, 30m, 40m and 50m kits, with aluminium profiles supplied in 2m sections to match the selected pack length.

Key Features & Benefits

• Complete outdoor recessed LED lighting pack – includes IP67 COB strip, matched 24V power supplies, extra-deep aluminium housing, opal diffuser, end caps and basic mounting accessories.
• Smooth, virtually dotless illumination – dense FCOB LED tape and diffuser help minimise visible LED spotting.
• IP67-rated sealed LED strip – designed to resist dust and temporary water immersion when its sealing and terminations remain intact; the rating applies to the tape, not automatically to the complete installation.
• High colour rendering, CRI 90+ – attractive illumination for natural stone, decking, planting and architectural materials.
• Choice of 3000K, 4000K or 6500K – select warm, neutral or daylight-white lighting for your project.
• 24V DC system – supplied with power supplies selected for your kit length.
• 11W per metre – clearly specified power consumption for planning electrical loads.
• Cuttable every 50mm – allows accurate on-site length adjustment at designated cut marks, followed by appropriate resealing.
• Extra-deep recessed aluminium channel – 26mm recess depth, supplied with opal diffuser in manageable 2m lengths.
• Multiple pack lengths – suitable for projects requiring 10m, 20m, 30m, 40m or 50m of linear LED lighting.

Where Can This In-Ground LED Lighting Be Used?

This outdoor recessed COB LED strip kit is intended for a wide range of carefully designed residential, retail, hospitality and commercial landscape and architectural linear lighting projects, including:

• Garden pathways, paved walkways and landscape borders
• Patios, terraces and decorative paving details
• Driveway-edge and entrance-area feature lighting, where the profile is protected from unsuitable traffic loads
• Outdoor steps, stair edges and low-level wayfinding accents
• Building façades, external walls and perimeter lighting
• Restaurants, hotels and hospitality exterior features
• Retail entranceways, outdoor display areas and commercial landscaping
• Recessed architectural light lines and bespoke exterior features

Important suitability note: The supplied dimensions do not establish a pedestrian or vehicle load rating for the aluminium profile. Confirm the mounting surface, expected loads, drainage and suitability of the housing before specifying it for a walk-on or drive-over location.

What Is Included in Your Complete Pack?

• IP67 high-CRI COB LED tape – selected colour temperature and total length between 10m and 50m
• Matched 24V LED power supplies – selected for the purchased kit size
• Extra-deep recessed aluminium floor housing – total profile length matched to the pack, supplied in 2m sections
• Opal profile diffusers and end caps – for a finished, softly diffused lighting line
• Basic mounting accessories – for installation of the supplied system

Additional items may be required: Suitable outdoor-rated cabling, including appropriately specified SY cable where appropriate to the installation, and weatherproof junction boxes or enclosures if any electrical connections or power supplies are installed outdoors. Cable and junction-box requirements depend on the site design and are not stated as included in the kit.

Ordering & Installation Advice

Step 1 – Choose your light colour: Select 3000K warm white, 4000K neutral white or 6500K daylight white.

Step 2 – Choose your pack length: Select 10m, 20m, 30m, 40m or 50m. We supply the corresponding LED strip quantity, matching 24V power supplies and 2m aluminium profile sections.

Step 3 – Plan your electrical installation: Confirm cable routes, driver locations, feed points, weatherproof terminations and drainage before installation. A 24V constant-voltage supply must be used; do not connect the LED tape directly to 230V mains.

Long runs: As specified for this system, lengths over 20m must be powered from both ends to help minimise voltage drop. Depending on the installation, additional feeds or separate circuits may also be necessary; the electrician must check cable losses, run layout and the permissible continuous tape length.

Recessing the profile: Prepare a flat, stable and properly drained channel with a 26mm recess depth, allowing for the complete profile dimensions, sealing method and substrate. The minimum specified strip bend radius is 30mm. Do not kink the tape or bend it more tightly than recommended.

Cutting and sealing: Cut only at marked 50mm cutting intervals. All cut ends, joins and cable entry points must be resealed using a suitable method to preserve the intended water protection. Installing an IP67 tape in a channel does not in itself make connections, drivers or the entire assembly IP67.

Driver location: Position power supplies in a suitable indoor or otherwise appropriately protected and ventilated location wherever possible. For outdoor locations, choose an enclosure with an appropriate environmental rating and provide suitable thermal management.

Installation and electrical connections should be designed and completed by a suitably qualified electrician, in accordance with applicable UK requirements and the conditions at the installation site.

Complete Your Outdoor LED Lighting Installation

Explore related lighting and electrical products from Manningham Lighting & Electrical:

• 24V LED Drivers and Power Supplies
• Weatherproof Junction Boxes
• SY Cable and Electrical Cable
• Aluminium LED Profiles and Diffusers
• LED Strip Lighting and LED Tape

Why Choose Manningham Lighting & Electrical?

• Established UK lighting and electrical supplier
• Outdoor LED strip lighting solutions for domestic, trade and commercial customers
• Project support covering driver sizing, cable feeds, recessed profiles and compatible accessories
• Complete kits to simplify the specification of longer linear lighting installations
• Support for electricians, landscapers, shopfitters and property professionals

Browse our complete range at www.manningham.co.uk.

Specification

Product Type	Complete Outdoor Recessed In-Ground COB LED Strip Lighting Kit
LED Strip Model	LUX-11WIP67-COB50
LED Technology	FCOB / COB (Chip on Board), continuous linear illumination
Operating Voltage	24V DC
Power Consumption	11W per metre
Colour Temperature Options	3000K Warm White / 4000K Neutral White / 6500K Daylight White
Colour Rendering Index (CRI)	90+
3000K Luminous Output	Approx. 957 lm/m (87 lm/W)
4000K Luminous Output	Approx. 1045 lm/m (95 lm/W)
6500K Luminous Output	Approx. 1056 lm/m (96 lm/W)
LED Tape IP Rating	IP67 (sealed tape, subject to correct treatment of all cut ends and terminations)
Cutting Interval	50mm, at designated cut points
Minimum Bend Radius	30mm or greater
Standard LED Tape Roll	50m
Available Kit Lengths	10m / 20m / 30m / 40m / 50m
Profile Type	Extra-Deep Recessed Aluminium Floor Housing
Profile Material	Aluminium with opal diffuser
Individual Profile Length	2m sections, quantity matched to selected kit
Recessed Depth	26mm
Profile Interior Width	12.6mm
Profile Exterior Bottom Width	21mm
Power Supplies Included	Matched 24V LED power supplies, sized to selected pack length
Additional Included Accessories	Opal diffusers, profile end caps and basic mounting accessories
Potential Additional Materials	Appropriately specified outdoor cable (including SY cable where suitable), weatherproof junction boxes and site-specific connection materials
Power-Feed Guidance	Runs over 20m to be powered from both ends; further feeds may be required depending on design
Typical Applications	Garden paths, patio details, landscape features, step accents, façades, external perimeter lighting, retail and hospitality exteriors

FAQs

What is included in the outdoor in-ground LED strip kit?

Each complete pack contains the selected length of IP67 COB LED tape, matching 24V power supplies, recessed aluminium housing supplied in 2m sections, opal diffuser, end caps and basic mounting accessories. External cabling and weatherproof junction boxes may need to be purchased separately.

What does COB LED strip mean?

COB stands for chip on board. The densely arranged LED chips produce a continuous line of light with far less visible spotting than many conventional LED strips. Together with the supplied opal diffuser, this provides an attractive, virtually dot-free architectural lighting finish.

Is the LED tape suitable for outdoor use?

The supplied sealed LED tape is rated IP67, making it suitable for appropriately designed outdoor applications. All cable connections, cut ends, drivers and enclosures must be protected according to their own ratings and the exposure expected on site. Good drainage is especially important for an in-ground recess.

Can this lighting be installed in a driveway?

It can be used for decorative driveway-edge lighting where the profile is suitably positioned and protected. A vehicle load rating has not been provided for this housing; do not assume it can be driven over. Confirm suitability before specifying it for any traffic-bearing surface.

Which colour temperature should I choose?

3000K warm white creates an inviting ambience for gardens and patios. 4000K neutral white provides a balanced, clean appearance for modern landscaping and pathways. 6500K daylight white gives a cooler, crisp effect for contemporary architectural accents and visibility-focused features.

How bright is the LED strip?

Approximate output is 957 lumens per metre at 3000K, 1045 lumens per metre at 4000K and 1056 lumens per metre at 6500K. The tape consumes 11W per metre. Actual installed output will be affected by the diffuser, mounting conditions and system design.

What is CRI 90+?

The colour rendering index indicates how naturally a light source reveals colours. With CRI 90+, this strip is suited to attractive lighting of stone, exterior finishes, landscaping and architectural details.

Can the COB LED tape be cut to length?

Yes. It can be cut at the marked 50mm intervals. Use the designated cut points only, and properly reseal every cut end or connection to maintain suitable environmental protection.

How deep is the recessed aluminium profile?

The specified recess depth is 26mm. The channel has an interior width of 12.6mm and an exterior bottom width of 21mm. Check the full installation detail, substrate and drainage before cutting the recess.

How are the aluminium profiles supplied?

Aluminium housing and diffuser are supplied in 2m sections, with a total length matched to the selected 10m, 20m, 30m, 40m or 50m pack.

Does the kit include the LED drivers?

Yes. Matched 24V LED power supplies are included and are selected for the chosen pack length. Additional electrical materials may be required depending on the installation layout.

How much power does a complete pack use?

At a nominal 11W per metre, the LED tape uses approximately 110W for 10m, 220W for 20m, 330W for 30m, 440W for 40m and 550W for 50m. These figures are total LED tape loads, not a recommendation to power each length as one uninterrupted run. Driver headroom, segmentation and feeds must be designed appropriately.

Do long runs need power from both ends?

Yes. The supplied guidance specifies both-end power feeding for lengths over 20m to limit voltage drop. Your electrician may need additional injection points or separate runs, depending on tape limits, cable lengths and the layout.

Do I need SY cable or a weatherproof junction box?

You may require site-suitable outdoor cable and a weatherproof junction box or enclosure, particularly where drivers or connections are positioned outdoors. SY cable was identified as an optional site-wiring material, but the final cable specification should be selected by the installer for the application.

Can I install the drivers outdoors?

Install drivers indoors or in a suitable protected position where possible. For outdoor locations, use appropriately rated equipment or a properly selected weatherproof enclosure, with ventilation and cable entries designed for the environment.

Can you help plan a bespoke project?

Yes. Our team can assist with kit selection, driver sizing, feed locations, cable planning, recessed profile choice and a project-specific connection diagram and bill of materials.

Project Help

Planning a recessed outdoor LED strip installation, an in-ground garden lighting feature or a longer commercial architectural lighting run? Speak with the Manningham Lighting & Electrical team, with over 25 years' experience in the lighting and electrical industry.

We can help with:

• Choosing between 3000K, 4000K and 6500K COB LED strip lighting
• Selecting a 10m, 20m, 30m, 40m or 50m complete lighting pack
• Calculating total wattage and specifying suitable 24V drivers
• Planning power injection, both-end feeds and cable routes for long runs
• Checking recessed channel sizes, profile positions and drainage requirements
• Identifying suitable cable, outdoor enclosures, connections and finishing accessories
• Preparing a tailored wiring diagram and bill of materials for larger projects
• Supporting domestic, landscape, hospitality, retail and commercial installations

For the most accurate recommendation, please share your required total length, chosen colour temperature, installation location, recess dimensions, photographs and proposed driver position. We can then help establish the appropriate components and installation approach.

Important: Always isolate the electrical supply before installation or maintenance. Work involving electrical connections should be completed by a suitably qualified professional where required.
